Torque Wrench 1/4" 5–25 Nm

This is a Yato click‑type torque wrench with a 1/4" drive and an adjustable working range of 5–25 Nm, intended for precise tightening of small fasteners in mechanics, automotive and industry. It uses a fine‑tooth ratchet head and calibrated mechanism to give an audible and tactile “click” when the set torque is reached.

Basic specifications

• Product name: Torque wrench 1/4" 5–25 Nm

• Model / symbol: YT‑07670

• Drive size: 1/4" (6.3 mm) square

• Working range: 5–25 Nm

• Accuracy: clockwise (CW) ±3%, counter‑clockwise (CCW) ±5%

• Ratchet: 72‑tooth head for small working arc and smooth operation

• Length: approx. 280–285 mm

Construction and features

The wrench uses an alloy‑steel body with an aluminium‑oxide or similar coated handle, giving good durability and corrosion resistance. A clear, engraved scale in Nm (sometimes also ft‑lb on some markets) and a locking mechanism on the handle allow you to set and lock the desired torque value. The 72‑tooth reversible ratchet lets you work in both CW and CCW directions, useful for left‑hand or difficult‑access fasteners within the stated accuracy.

Typical applications

With its 5–25 Nm range and 1/4" drive, this wrench is ideal for:

• Smaller automotive and motorcycle fasteners, engine covers, and precision assemblies

• Bicycle components, electronics housings and machinery where low torque and accuracy are critical

• Any job where over‑tightening could damage threads, gaskets or delicate parts.
